Advantages of the Silver Electrolytic Unit
- Cathode Current Density: 750 A/m²
- One-Piece Electrolytic Cell Design: Eliminates electrolyte leakage risks.
- Electrolyte Cooling and Temperature Control: Maintains optimal operating conditions.
- Stable Product Quality: Electrolytic silver powder consistently achieves ≥99.99% purity.
- Transparent Enclosed Fume Cover with Side Exhaust: Ensures a clean and safe working environment.
- Electrolyte Cooling System: Reduces electrolyte volatilization and minimizes acid consumption.
- Fume Condensation System: Cools exhaust gases to prevent silver loss during processing.
- Material Specifications: The main cell body is constructed from high-performance polypropylene (PP) reinforced with anti-aging additives, significantly extending its operational lifespan, while the integrated support frame is made of PPH material, demonstrating exceptional corrosion resistance for long-term durability. Both the anode and cathode busbars utilize titanium-clad copper, ensuring superior electrical conductivity and reliable performance in electrolytic applications.
Technical Parameters
| Model | Dimensions | Pure Gold Precipitation Capacity | Power(kw) | Power Supply | Material |
| JQ-JDJ-20 | 1500*700*1850mm | 20kg/d | 3 | 380V | PPH |
| JQ-JDJ-50 | 1600*800*1900mm | 50kg/d | 8 | ||
| JQ-JDJ-100 | 570*840*1200mm | 100kg/d | 11 | ||
| JQ-JDJ-200 | 1200*840*1300mm | 100kg/d | 23 | ||
| JQ-JDJ-300 | 1930*840*1300mm | 300kg/d | 35 |
